IFIX6G2W
iFIX6G2 120W RMS FULL RANGE, DEEP BASS, HIGH-END SOUND QUALITY
Installation
Features
- Real 120W RMS power capacity (8 hours pink noise)
- Architectural pleasing design available in white, black and natural wood colors
- Highly dynamic and smooth reproduction
- Premium custom made coaxial European driver
- Shipped with wall mount bracket
- Tropicalized for outdoor use
- Match with iFix 13s or 17s high power subwoofers for extended low frequency, high quality music reproduction
Cabinet Dimensions
Specifications
| Power Capacity (50~15000Hz pink noise 8 hours): | 120W RMS /480W Peak |
|---|---|
| Nominal Impedance: | 12ohm |
| Frequency Response (-6dB): | 65Hz - 22kHz |
| Sensitivity: | 90dB/W/m |
| Max Calculated SPL @ 1m: | 111dB continuous / 117dB Peak |
| Directivity: | 85º x 85º |
| Recommended Low Cut Filter: | 100Hz 24bD/Oct with iFix13S |
| Low LF Driver: | Custom Celto 6" Ferrite 1.5" Coil |
| High HF Driver: | Custom Celto 0.75" 1.1" Titanium Diaphragm Coaxial |
| Crossover: | 2500Hz |
| Flying Hardware: | Integrated Multi-function Yoke |
| Connectors: | Screw Terminal |
| Pole Mount: | With Optional Adapter |
| Cabinet | 12mm Birch Ply, Painted |
| Net Weight: | 5.5Kg |
| Gross Weight | 7.5Kg |
| Dimensions (W x D x H): | 260 x 190 x 250mm |
| Packaging Dimensions 1pcs/pack: (W x D x H) |
330 x 370 x 360mm |
| Warranty: | 5 Years |
